CNC YCB6HLE-63 1P+N 63A RCBO Earth Leakage Breaker – 30mA

CNC 63A RCBO Earth Leakage Breaker

The CNC Electric YCB6HLE-63 is supplied as a 1P+N 63A RCBO for earth leakage and overcurrent protection. The pictured unit is marked C63, IΔn 0.03 A and IEC 61009-1. Its linked red handle and separate test and reset controls provide accessible front-panel operation in an appropriately designed electrical distribution installation.

Product Details

• Brand: CNC Electric
• Model shown: YCB6HLE-63
• Configuration: 1P+N, as supplied in the product name
• Rated current: 63 A; C63 marking shown
• Residual-current marking: IΔn = 0.03 A (30 mA)
• Frequency marking: 50/60 Hz
• Additional visible markings: 4500 A; t ≤0.1 s
• Printed standard: IEC 61009-1
• Controls: Linked red operating handle, blue control labelled “Push before switching on,” and orange T button labelled “Push monthly”
• Terminal markings: Neutral (N) and LINE OUT markings visible

Selection and Installation

Have a qualified electrician confirm the exact voltage rating, pole arrangement, residual-current type, breaking capacity and suitability for the intended circuit from the manufacturer datasheet and the supplied unit. The photograph's voltage print is not sufficiently clear to establish a reliable operating-voltage specification. Printed markings are reported from the photo and are not independent certification verification.

Install and test according to the manufacturer's instructions and applicable electrical requirements. Earth leakage protection does not replace correct earthing or safe electrical practices. Do not assume suitability for DC circuits or solar inverter applications without manufacturer confirmation. This is a separate 63A model, not the previously listed 32A breaker.
