CNC YCM1-125L AC 3 Pole MCCB 20A Molded Case Circuit Breaker 400V | Safe & Reliable Protection

CNC YCM1-125L AC 3 Pole MCCB, 20A

The CNC Electric YCM1-125L 3 Pole Molded Case Circuit Breaker protects 3-phase circuits from overload and short circuits in a compact, rugged body. At 20A, it suits smaller 3-phase loads such as motors, pumps, and sub-panels that need the durability and higher breaking capacity of an MCCB instead of a regular MCB.

Specifications

• Model / Frame: YCM1-125L/3300
• Poles: 3 Pole
• Rated Current: 20A
• Rated Operating Voltage (Ue): AC 400V, 50Hz
• Rated Insulation Voltage (Ui): 800V
• Rated Impulse Voltage (Uimp): 8kV
• Breaking Capacity (Icu / Ics): 35 / 22 kA at 400V
• Reference Temperature: +40°C
• Standard: IEC 60947-2

Features

• Clear ON / OFF handle: with a red ON indicator
• Push-to-trip button: for quick mechanical testing
• Heavy-duty screw terminals with phase separators
• Rugged molded case for industrial conditions

Applications

• 3-phase motors, pumps, and compressors
• Industrial and commercial sub-distribution panels
• Machine control panels
• 3-phase solar inverter AC output protection

Need a different rating? Contact Golden Sun Solar.
