Max Power PV Tech 15000 Solar Inverter with MPPT
Max Power PV Tech 15000 Solar Inverter with MPPT
Couldn't load pickup availability
Solar Charging and Battery Backup for Your Power System
The Max Power PV Tech 15000 combines pure sine wave output, MPPT solar charging and compatible battery storage for appropriately designed solar installations. Its specified 48V battery system and up to 15kW PV input capacity provide a starting point for planning solar and storage integration.
For homes, offices and commercial sites, a professionally sized system can support selected loads during grid outages when sufficient battery energy is available. Actual backup duration depends on battery capacity, state of charge and power consumption.
Key Features
- Pure sine wave output
- MPPT solar charging technology
- 48V battery system support
- Up to 15kW PV input capacity, supplied specification
- Compatible lithium-ion and lead-acid battery options
- RS232, RS485 and CAN communication interfaces listed
- Front-panel display and operating controls
- 24kVA surge capacity, supplied specification
Product Specifications
| Parameter | Value |
|---|---|
| Brand | Max Power |
| Model | PV Tech 15000 |
| Output waveform | Pure sine wave |
| Battery system | 48V |
| Maximum PV input capacity, supplied specification | 15kW |
| Solar charging | MPPT |
| Battery options | Compatible lithium-ion, AGM and gel batteries |
| Communication interfaces listed | RS232 / RS485 / CAN |
| Surge capacity, supplied specification | 24kVA |
Frequently Asked Questions
Does PV Tech 15000 support lithium batteries?
Compatible lithium-ion batteries can be used subject to the required voltage, charging settings and BMS compatibility. Confirm the exact supported battery model before connection.
Can it provide backup during load shedding?
Backup operation requires a correctly configured system and sufficient available battery energy. Transfer performance and load compatibility must be checked; uninterrupted electricity for every appliance is not guaranteed.
How much solar capacity can be connected?
The supplied PV input capacity is up to 15kW. Panel strings must also comply with the exact model's voltage and current limits. PV input capacity is separate from continuous AC output power.
Is it suitable for heavy loads?
The supplied 24kVA surge rating does not by itself establish compatibility with motors, pumps or air conditioners. Verify continuous output power, surge duration and appliance starting demand with an installer.
System Design and Installation
Confirm the exact continuous AC output rating and efficiency from the manufacturer's model-specific datasheet before sizing loads. Have a qualified solar professional design the PV strings, battery bank, protection, cable sizing and earthing. Communication interfaces do not alone confirm included remote-monitoring accessories or services.
