Sofar 60K/80KTLX-G3 Three-Phase On-Grid Solar Inverter Series
Sofar 60K/80KTLX-G3 Three-Phase On-Grid Solar Inverter Series
Couldn't load pickup availability
Three-Phase Grid-Tied Power for Commercial Solar Arrays
The Sofar 60K/80KTLX-G3 series offers 60kW and 80kW rated-capacity models for professionally designed commercial rooftops, factories and warehouses. This series overview distinguishes the supplied model-specific power ratings; confirm the exact model selected before purchase.
Capacity Comparison
| Parameter | 60kW model | 80kW model |
|---|---|---|
| Rated output | 60kW | 80kW |
| Maximum DC input power, supplied specification | 90,000W | 120,000W |
Key Features
- Three-phase on-grid configuration
- 6 independent MPPT trackers, supplied series specification
- 2 DC inputs per MPPT, supplied series specification
- 180–1000V MPPT operating range
- 200V startup voltage
- 1100V maximum DC input voltage
- Up to 98.8% peak conversion efficiency
- 98.4% European efficiency, supplied specification
Protection Functions
Listed protection features include DC reverse-polarity protection, anti-islanding, ground-fault monitoring and Type II AC/DC surge protection. These features do not guarantee continuous operation through every fault, outage or environmental condition.
Frequently Asked Questions
What is this series used for?
It converts solar DC power for appropriately designed three-phase grid-connected commercial and industrial installations.
How many panels can be connected?
Panel count depends on the selected 60kW or 80kW model, module wattage, string voltage and input-current limits. The supplied DC power ceilings are 90kW and 120kW respectively; these figures alone do not establish a safe string layout.
Can it work with high-power panels?
Suitable high-power modules may be used when their voltage and current characteristics comply with the exact inverter's limits. Panel wattage alone does not establish compatibility.
Does this provide battery backup?
This listing describes an on-grid inverter, not a hybrid battery inverter. Do not assume direct battery connection or outage backup support. Any storage integration requires separately verified compatible equipment and professional system design.
Installation Notes
Confirm all model-specific specifications in the manufacturer's datasheet before purchase and installation, including MPPT count, string-current limits and efficiency. A qualified solar professional must assess cold-weather open-circuit voltage, protection, earthing, grid requirements and utility approval. MPPT tracking does not eliminate shading losses or guarantee generation during every low-light period.
