SUNTREE AC 60kA Surge Protective Device SPD 4 Pole 3L+N 385V Type 2

Heavy-Duty 60kA Surge Protection for Solar & Electrical Systems

The SUNTREE AC 60kA Surge Protective Device is built for sites that face frequent lightning and heavy grid switching surges. With a high 60kA maximum discharge capacity, it gives your distribution board, solar inverter, and connected appliances an extra margin of safety in 3-phase (3L+N) systems, diverting dangerous surge energy to earth in nanoseconds.

Key Features

• 60kA maximum discharge capacity for high-exposure and lightning-prone areas
• Fast response clamps spikes before they reach sensitive equipment
• Thermal disconnector safely isolates the module at end of life
• Visual status window on each pole for quick health checks
• 4 Pole (3L+N) complete three-phase + neutral protection
• 35mm DIN rail mounting for quick, clean installation

Technical Specifications

• Brand: SUNTREE
• Type: AC Surge Protective Device (SPD), Type 2
• Poles: 4P (3L+N)
• Max Continuous Operating Voltage (Uc): 385V AC
• Maximum Discharge Current (Imax): 60kA
• Mounting: 35mm DIN rail

Ideal Applications

• Solar PV systems, inverter AC output side
• Commercial and industrial distribution boards
• Three-phase power systems, factories, and plazas
• Protection for CCTV, networking, and sensitive electronics

Install by a qualified electrician with proper earthing (PE) connection.
